FusionServer 5288 V6 Rack Server

Model： FusionServer 5288 V6
Form Factor： 4U Rack Server
Processors： 1/2 3rd Generation Intel Xeon scalable processor (Ice Lake) (8300 / 6300 / 5300 / 4300 Series) , up to 270W
Chip Set： Intel C621A
Memory： 32 DDR4 memory slots, up to 3200 MT/s; Up to 16 Intel Optane TM Persistent Memory 200 Series, up to 3200MT/s

Technical SpecificationsModel : FusionServer 5288 V6

Form Factor : 4U Rack Server

Processors : 1/2 3rd Generation Intel Xeon scalable processor (Ice Lake) (8300 / 6300 / 5300 / 4300 Series) , up to 270W
Chip SetIntel C621A

Memory : 32 DDR4 memory slots, up to 3200 MT/s; Up to 16 Intel Optane TM Persistent Memory 200 Series, up to 3200MT/s

Local Storage : Various hard disk configurations are supported. The hard disks are hot swappable: 36 to 44 3.5-inch SAS/SATA HDDs and 4 NVMe SSDs. 24 x 3.5-inch SAS/SATA front hard disks. 4 3.5-inch SAS/SATA internal hard disks. 16 3.5-inch SAS/SATA hard disks and four 2.5-inch SAS/SATA/NVMe rear hard disks. 12 3.5-inch SAS/SATA disks and eight 2.5-inch rear hard disks (4 x 2.5 HDDs + 4 x 2.5 SAS/SATA/NVMe). Flash storage: Dual M.2 SSDs

RAID Support : Supports RAID 0, 1, 5, 50, 6, and 60, cache supercapacitor protection, RAID level migration, disk roaming, self-diagnosis, and web-based remote configuration, and multiple network expansion capabilities

Network : OCP 3.0 NIC, The two FLEX I/O card slots support two OCP 3.0 NICs, which can be configured as required, Supports multiple OCP 3.0 NICs, Supports hot swap

PCIe Expansion : A maximum of 11 PCIe 4.0 slots, including one dedicated PCIe slot for the RAID controller card, two dedicated FLEX I/O slots for OCP3.0, and eight standard PCIe 4.0 slots

Fan Modules : 4 hot-swappable fans, supporting N+1 redundancy

Power Supply : 2 redundant hot-swappable PSUs are configured in 1+1 redundancy mode. The optional specifications are as follows: 900W AC Platinum/Titanium power supply (Input: 100C240 V AC or 192C288 V DC) 1500 W AC Platinum PSU 1000 W (input: 100 V AC to 127 V AC) 1500 W (input: 200C240 V AC or 192C288 V DC) 2000 W AC Platinum PSU 1800 W (input: 200C220 V AC or 192C200 V DC) 2000 W (input: 220C240 V AC or 200C288 V DC)

Management : The BMC chip integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening. The BMC supports standard interfaces such as Redfish, SNMP, and IPMI2.0. Provides a remote management interface based on HTML5/VNC KVM. Supports out-of-band management functions, such as monitoring, diagnosis, configuration, agentless, and remote control, simplifying management FusionDirector management software can be used to provide advanced management features such as five intelligent features, implementing intelligent, automatic, visualized, and refined management throughout the lifecycle

Operating Systems : Microsoft Windows ServerSUSE Linux Enterprise ServerVMware ESXiRed Hat Enterprise LinuxCentOSOracle LinuxUbuntuDebianopenEuler etc

Security Features : Security features such as power-on password, administrator password, TPM 2.0, security panel, secure boot, and cover opening detection

Certification : CEULCCCFCCVCCIRoHS etc

Installation Kit : L-shaped guide rails, retractable guide rails, and holding rails

Dimensions (H x W x D) : Chassis dimensions: 175 mm x 447 mm x 790 mm
