Features :
– High power density
– Graphical LCD display
– Built-in energy meter
– Intelligent battery management system
– Lithium-ion battery pack
– Operate without battery
– Longer lifecycle
– Lighter weight
– Intelligent battery management system
– Certified Lithium-ion batteriesTechnical Specifications :
– Output power capacity : 2700Watts / 3000 VA
– Nominal output voltage : 230V
– Output voltage distortion : Less than 1% at linear load (Full)
– Output frequency (sync to mains) : 50/60 Hz +/- 3 Hz (auto sensing)
– Waveform type : Pure Sine Wave
– Output connections : (6) IEC320 C13, (2) IEC320 C19
– Efficiency at full load : >96%
– Nominal input voltage : 230V
– Input frequency : 50/60 Hz +/- 3 Hz (auto sensing)
– Input connections : IEC-60320 C20
– Input voltage range for main operations : 160-275V (10V minimum hysteresis, ±1.5% max measurement accuracy)
– Battery type : Lithium-ion NMC chemistry (LiNiMnCoO2)
– Additional external battery packs : up to 10
– Interface port(s) : Serial (RJ45), Smart-Slot, USB
– Available SmartSlot interface quantity : 1
– Emergency Power Off (EPO) : 1
– UPS Net Dimension (HxWxD): 85mm x 432mm x 639mm
– UPS Shipping Dimension (HxWxD) : 245mm x 600mm x 870mm
– UPS Rack Height : 2U
– UPS Net / Shipping Weight : 17.5kg / 25kg
– External Battery Pack Net Dimension (HxWxD) : 43mm x 432mm x 521mm
– External Battery Pack Shipping Dimension (HxWxD) : 200mm x 600mm x 850mm
– External Battery Pack Rack Height : 1U
– External Battery Pack Net / Shipping Weight : 13kg / 16.4kg
– Audible noise at 1 meter from surface of unit : 50.0dBA
– Standard warranty : 5 year repair or replace
