UPS APC 3 Phase 10kVA 10kW 380V/400V/415V E3SUPS10KHB + E3SBT4

Easy UPS 3S 10 kVA 400 V 3:3 UPS for internal batteries
APC UPS 3-PHASE EASY 3S 10kVA BACK UP TIME 30 MINUTES AT FULL LOAD PF 0.9 VRLA BATTERY

Include :
– E3SBT4 Easy UPS 3S Battery String x3
– E3SOPT001 Easy UPS 3 Series Network Card x1
– WSTRTUP-EZ-15 Start-Up Service 5X8 for (1) Easy UPS 3S 10 – 15kVA UPS x1

Features:
– Easy to install and start up
– Available in 10 – 40kVA
– Power Factor 0.9
– Extended runtime
– Easy to expand up to four UPSs
– Quickly and easily replace the dust filter conveniently located behind the front door.
– Monitoring of UPS status remotely through a Web interface (optional)
– Easy Loop test verifies UPS performance before you connect your load, without the need for a load
bank
– On-site start-up* with Schneider Electric Field Service Representatives (mandatory)

SpecTech:
– Main Input Voltage : 400 V 3 phases
– Input Voltage: 380 V, 415 V
– Input Frekuensi: 45 – 65 Hz
– Main Output Voltage : 400 V 3 phases
– Output Voltage: 380 V, 415 V
– Output Frekuensi :50 – 60 Hz sync to mains
– rated power in W: 10.0kWatts
– rated power in VA : 10.0kVA
– provided equipment : Dust filter,Installation guide
– maximum input current : 18 A
– Input Power Factor at Full Load : 0.9
– UPS type : Double conversion online
– battery type : VRLA
– battery voltage : 240V

Net Weight: 440 KG ( UPS + Battery)
Shipping Weight: 500 KG ( UPS + Battery)
Physical HxWxD: 140 x 38 x 93 cm
Shipping HxWxD: 164 x 57 x 102 cm
Protection Class: IP20
Standard Warranty: 1 year on-site with factory authorized Start-Up
